XBO 2200 W/DHP OFR
Características del producto
- Short arc with highest luminance for brighter screen illumination
- A lifetime of reliable performances with constant 6000 K color temperature
- Easy to maintain
- High level of arc stability
- Hot restart and instant light on screen
- Dimmable in a wide range
Áreas de aplicación
- Digital Cinema Projection
Instrucciones de seguridad
Because of their high luminance, UV radiation and internal pressure in both the hot and cold state, XBO lamps may only be operated in enclosed lamp casings specially constructed for the purpose. Xenon lamps are highly explosive. When hot, xenon lamps can cause burn marks. They should only be handled when the lamp is at room temperature. Always use the protective jackets supplied when handling these lamps. When packing the lamps and when installing or removing the lamps without their protective jackets, always wear protective clothing (face shield with neck protector, protective jacket and lint-free, cut-resistant gloves). For more information see the relevant in-pack leaflets and operating instructions.
Because of their high luminance, UV radiation and internal pressure in both the hot and cold state, XBO lamps may only be operated in enclosed lamp casings specially constructed for the purpose. Xenon lamps are highly explosive. When hot, xenon lamps can cause burn marks. They should only be handled when the lamp is at room temperature. Always use the protective jackets supplied when handling these lamps. When packing the lamps and when installing or removing the lamps without their protective jackets, always wear protective clothing (face shield with neck protector, protective jacket and lint-free, cut-resistant gloves). For more information see the relevant in-pack leaflets and operating instructions.
Alta luminosidad
Throughout lamp life - Thanks to dimmabilityDCI-compliant
Extensive color space - Thanks to Xenon fillingAll screen sizes covered
Thanks to extensive product rangeFabricado en Alemania
Automated processing of high quality materials and strict quality controls ensures a consistent high lamp standardDatos técnicos
Información general del producto
NAED5
67484
Description
XBO 2200W/DHP 1/CS 1/SKU
Lamp Type
XENON
Texto corto producto
XBO 2200 W/DHP OFR
Datos eléctricos
Potencia nominal
2200 W
Tensión nominal
24.0 V
Corriente nominal
85 A
Margen del control de corriente
68…95 A
Tipo de corriente
DC
Datos Fotométricos
Flujo luminoso
92000 lm
Long. del centro luminoso (LCL)
123,0 mm
Physical Attributes & Dimensions
Distancia entre electrodos en frío
3,7 mm
Casquillo ánodo (denominación norma)
SFaX27-14x80
Casquillo cátodo (denominación norma)
SFc27-16/55
Diámetro
52.0 mm
Diameter (in)
2.047 in
Largo
345.0 mm
Long. con casq pero sin pitones/conexión
295,00 mm
Longitud del cable de entrada
130 mm
Conector: Presencia [PICOS]
Yes
Peso del producto
534.00 g
Temp. y condiciones de funcionamiento
Posición de quemado
s 15 p 15
Enfriamiento
Refrigeración forzada
Temp. amb. máx. permi. punto de pinzado
230 °C
Duración de vida
Average Rated Life
2400 hr
Warranty Hours [PIM]
1500 hrs
Service Warranty Lifetime
2000 hr
Información medioambiental y regulatoria
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Identificador principal del artículo
4008321865489 | 4062172030373
Nº de declaración en la base de datos SCIP
5e903ee1-3cc9-40f0-ae95-0a54da9c2b3a
Lista de candidatos Sustancia 1
Lead
Nº CAS de la sustancia 1
7439-92-1
Instrucción de uso seguro
La identificación de la sustancia de la lista de sustancias candidatas es suficiente para permitir el uso seguro del artículo.
Información de embalaje
EAN |
Unidad |
Pieza |
Dimensiones |
Peso |
Volumen |
|---|---|---|---|---|---|
| 4062172030373 |
VS
| 1 | 500mm x 204mm x 204mm | 1330.00g | 20.81dm³ |
